Sematic 2000 C-MOD Landing Door

Doors for modernization

Sematic 2000 C-MOD Landing Door

Enhancing performances, passenger safety and comfort in existing lift systems

Do you need to upgrade your existing lift doors to comply with EN81-80 requirements? Do you need a compact, flexible solution for modernization without giving up performance, quality, cost and safety? Sematic 2000 C-MOD is the answer.

Featuring a wide range of options, 2000 C-MOD doors come with or without frame, giving flexibility to your installation’s needs. Car doors can be coupled with automatic or manual swing landing doors, for those situations that need car door upgrade only. They can both be equipped with Sematic Drive System (SDS) controller for higher performances and control or with SZS for cheaper solutions.

Sematic 2000 C-MOD has a minimum 117mm bottom track package, making it a small and compact solution, without giving up the robustness and quality that are typical of our products.

Product Range
Model	TB min-max (mm)	TH min-max (mm)
K-S 2R/L	600 - 1400	2000 - 2300
K-S 3R/L	600 - 1400	2000 - 2300
K-S 2Z	600 - 1400	2000 - 2300
K-S 4Z	600 - 1400	2000 - 2300

For further infomation see our technical catalogues

Bottom Track Park Overall Dimension (mm)
Opening	K(car)	S(landing)	Pack⁽¹⁾
2R/L	67	90	185
3R/L	100	135	273
2Z	32	52	117
4Z	67	90	185

(1) 28mm sill distance

Door Opening Type

FIRE RATED EXEXUTIONS - EN 81-58
Model	Steel Doors	Framed Glass Doors
S2 R/L	E 120 EW 60 EI 60 EI 120	E 120
S3 R/L
S2Z
S4Z

BS 476, GOST and many other certifications available. Call for information.

K - CAR DOOR
2R/L	3R/L	2Z	3Z
C-MOD K-AUT-B(for automatic landing door)
♦	♦	♦	♦
C-MOD K-MAN(for manual swing landing door)
♦	♦		♦

K - LANDING DOOR
2R/L	3R/L	2Z	3Z
C-MOD-BF(with Boxed Frame)
♦	♦	♦	♦
C-MOD-N(Naked, without frame)
♦	♦	♦	♦
C-MOD-N-GC(Naked Gap Closing)
♦	♦		♦

DOOR AND FRAME FINISHES	STANDARD	OPTIONS
RAL 7032 powder coating
Other RAL Colours
Framed glass
Stainless steel claddings
Skin plate claddings

BOTTOM TRACK	STANDARD	OPTIONS
Aluminum
Galvanized Iron
Stainless Steel AISI 304
Stainless Steel AISI 316

MAIN FEATURES	STANDARD	OPTIONS
Certified locking device	EN81-1/2 EN81-20/50
Position of the lock release	In the panel (in the header for EN81-20/50 and TH>=2100)
Door closing	Spirator	Counterweight or spring
Door panels	Single skin	Double skin
Header height	240 mm 265 mm for 3 RL
Frame	Boxed 100×60 mm door posts	Naked Naked gap closing Boxed 120×60 mm door posts
Installation	Sill in the shaft and frame on the floor	In niche
Kit man in the pit	In case of EN81-20/50	In case of EN81-1/2
Monostable contact
Impact robust packaging	Single packaging	Cardboardbox Wood(ISPM15)
